500kg mini nplua steer loader HT500 nrog daim ntawv pov thawj CE

Cov Khoom Taw Qhia 500kg mini nplua steer loader

HT500 mini nplua steer loader yog ib tug suav bobcat hom mini nplua steer loader nrog loading peev 500kg.The skid steer loaders nruab nrog universal ceev coupler phaj, uas yuav txuas nrog nrog varous hom attachments nyiam 4 hauv 1 thoob, auger, rauj, sweeper , daus hniav, daus blower, trencher thiab lwm yam.Nws yog ntau yam siv los siv rau hauv cov pej xeem tej hauj lwm, kev tsim kho tej yaam num, ua liaj ua teb thiab lwm yam.

图片 16 (001) .jpg

Cov kev ntsuas loj ntawm Skid Steer Loader

Zuag Qhia Tag Nrho
Kev khiav hauj lwm hnyav	2300 kg
Tag Nrho Qhov Ntiaj Teb L × W × H	2950 × 1400 × 2000 hli
Thoob Plaws	0.3 m³
Rated Load	500 kg
Log Hom	8.5-15
Roj Tank Capacity	60 L
Hydraulic txheem Flow	60 L / Min
Cav
Qauv	Changchai 390 / Yanmar 4TNE92
Rated zog	30/2650 kw / rpm 33/2450 kw / rpm
Ua Hauj Lwm Ntau
Max mus txog qhov siab	3300 hli
Max Dumping Qhov siab	2050 hli
Min Dumping Deb	790 hli
Pem hauv ntej Txoj Kev Radius	1760 hli
Tsheb Turing Radius	1296 hli
Steering Hom	Nplua Steering
Kev Tswj Xyuas Kev Ua Haujlwm	Mechanical Joystick / Hydraulic Joystick

Khoom Paub meej ntawm 5 00kg Mini Nplua Steer Loader

1, kev teeb tsa

HT500 mini nplua steer loader txais Bondioli Pavesi hom valve los ntawm ltalis, Sauer Danfoss hom twj thiab Eaton lub cav tsav ntawm USA.Yanmar cav yuav tsum nruab rau kev xaiv kom tau raws li EPA 3 los yog Euro 3 emission standard.The hydrostatic kis tau tus mob yuav ua rau lub xeem loader ntau npaum.

图片 17 (001) .jpg

2, Tswj System

On standard configuration nws txais txhua yam kev ua si joystick tswj tab sis hydraulic joystick system kuj muaj peev xwm yuav nruab rau kev xaiv kom ua haujlwm ntau txoj haujlwm.

3, Sab hauv lub txee

Dashboard yog nyob rau pem hauv ntej sab saum toj ntawm lub txee, nrog rau cua sov, teev xaj thiab huab cua, kaw lub txee rau kev xaiv. Kev ruaj ntseg ntawm txoj hlua thiab kev nyab xeeb kom paub tseeb tias kev nyab xeeb ntawm tus neeg tsav tsheb.

图片 18 (001) .jpg

4, Sab nraud cov ntsiab lus

图片 19 (001) .jpg

5, Ntxuas

HT500 mini nplua steer loader txheem nruab nrog hydraulic auxiliary kab thiab thoob ntiaj teb universal hom ceev coupler.various hom attachments nyiam pallet diav rawg, 4 hauv 1 thoob, rauj, auger, sweeper, tov khoom thiab lwm yam yuav tsum txuas nrog lub tshuab.Nws yog multifunctional kom tau raws li ntau hom haujlwm hauv qhov chaw nqaim.

图片 20 (001) .jpg

Ntim & Tsheb Thauj

2 units HT500 mini skid steer loaders tau muab tso rau hauv ib lub thawv 20GP thiab nws yuav raug kho zoo los ntawm kev siv.

图片 21 (001) .jpg
